Product Zone



Our Philosophy...

Rolt strive to manufacture equipment that will meet the requirements of our clients, we listen and dedicate our designs around your needs, to deliver a product that’s easy to use and will run first time every time, print after print.

If you feel that you need something special contact us and we will deliver!



Product Detail



Key Features

Below are the standard key features of a Rolt Print Press.

  1. ๏Keypad operator control panel for setting of repeat length and run quantity.

  2. ๏Diagnostic display: shows what the machine is doing next.

  3. ๏Electronic ‘x’ axis registration along the web.

  4. ๏Pneumatic control of impression.

  5. ๏Adjustable squeegee and flood bar speeds.

  6. ๏Quick detach squeegee and flood blade apparatus.

  7. ๏Automatic peel.

  8. ๏Adjustable off contact.

  9. ๏Adjustable squeegee angles.

  10. ๏Batch counter.

  11. ๏Modem can be connected for remote diagnostics or upgrades.

  12. ๏Safety guards and emergency stop switch.





Print Press

High speed flatbed design for registration printing on all types of label stock. Ceramic transfer, Membrane circuits and Thermal transfers.





Product Overview

This printer is a simple high speed flatbed design for registration printing of all types of label stock, various transfer substrates and electronic circuits. The printer will deliver a good 15 metres per minute quotable speed with a quick turnaround. It has a strong double-sided squeegee mounting with an air regulator to set the squeegee pressure.

This design pre-longs stencil life and minimises the distortion of the screen. The most common print area is 330mm wide x 500mm long, and the maximum web width is 350mm, 150mm minimum. It should be noted that multiple up printing can be done and re-registered on a finishing line. The registration system makes the machine ideally suitable for overprinting webs from other machines, such as flexo or offset.





What’s New

  1. ๏The Rolt ‘x’, ‘y’, ‘theta’ registration system. Registration accuracy of approximately 0.05mm can be achieved.

  2. ๏Electronic Pneumatic control of impressions.
